PSS2302. APP + infrared remote control portable lift heater. (2000W fast heating of the apricot white standard edition). - PSS2302

EAN:
SKU: PSS2302. APP + infrared remote control portable lift heater. (2000W fast heating of the apricot white standard edition).

technical parameter
Applicable standard: US / EU
Rated voltage: 110V / 230V
Frequency: 50Hz
Rated power: 2000W (+ 5% / -10%)
Technical standard: ambient temperature: 23℃ ± 2℃
Wind speed standard: temperature: 1.25 m/s temperature wind: 120℃ sleep: 1.1 m/s. [] Anemometer 20cm away from the wind net
Dumping standard: 15° No dumping
Noise standard: 1 gear, 2 gear: <55 db 3 gear: <52 db
High and low temperature constant humidity:
High temperature: 60℃
Humidity: + 85%, 48h
Low temperature: -15℃, 48h
Operating mode: a rotary switch
Low temperature gear: PTC1000W + motor high-grade, working power 1150W ± 10%
High temperature gear: PTC2000W + motor high-grade, working power 2000W ± 10%
Sleep gear: PTC1000W + motor low gear, working power of 920W ± 10%

Commodity characteristics
1. Portable lifting and warm air, free lifting, free elevation;
2. From the room to the hall, where the cold put where, customized exclusive heating "comfort zone";
3. Upgrade the heating black technology, more suitable for multiple scenes and multiple space, innovative lifting design, accurate heating, PTC ceramic heating, 1 second heating, tubular high wind volume, the whole house uniform heating, 2000W power, can warm 30 m² large space;
4. PTC ceramic heating, 1 second heating frequency conversion power saving, PTC heating faster heating, accelerated to reach the preset temperature, automatic low power operation;
5. Meet the target temperature quickly, and enter the EC.O power-saving mode faster;
6. Surging tubular warm air, can warm 30 m² large living room, the whole house fast heating through;
7. Up and down 80° adjustment, heating;
8. Intimate sleep mode, noise reduction without light, comfortable and good sleep;
9.2nd gear warm air. A variety of options for 1000W local precision heating; 2000W whole house uniform heating;
10. Multiple protection. Peace of mind heating, dumping 15° power off, ABS flame retardant shell, overtemperature automatic power off.

Product size: 410 * 410 * 627mm
Packing size: 430 * 225 * 465mm
Package quantity: 1PC
Package weight: 4.3 KG
Packing specification: mm
Boxed quantity: PCS
Pgross weight: KG

product function
1. Switch button:
A. Turn on once, default warm air mode (25°) (heating indicator, digital indicator, temperature indicator on.)
B. Press off again, and turn down the buzzer (drop) for 1.2 seconds long. After shutting down, the fan needs to run for 30 seconds before shutting down, and a digital indicator light needs to count down for 30 seconds.[Shutdown standby state all icons off (including WIFI icon). If you touch all the function buttons or use a shake controller or APP, you can wake up the corresponding function icon currently in operation.-Pro & Max] Shutdown standby All icons off. If you touch all the function buttons or use the shake controller, you can wake up the corresponding function icon currently in operation.
c. Memory function, boot again memory the last setting mode, corresponding to the indicator light (remember the last selected timing time). After the last shutdown, there is a warm air mode (25°) before the shutdown to run for 10 seconds two fans and two groups of PTC at the same time, two motors in the second gear, two groups of PTC open the first gear power 1500W to remember the last setting mode.
2. Humet key:
A effectively press the humidification indicator button on, the default digital light (01) flashing for the first time, the humidification key 01-06-00-01, the humidification indicator off, water shortage indicator light flashing, the buzzer to remind 10 seconds, after the anti-dry burning function start, no operation, the switch off humidification mode, the water shortage indicator out.
3. Heating key:
Heating indicator lights, temperature indicator lights are on, Press the heating button digital screen flashing for 2 seconds to show the set temperature 25 degrees two fans and two sets of PTC at the same time, Two motors are operating in second gear, Two sets of PTC open one gear power 1500W (MAX) / 1250W (PRO), Press the heating button again and the digital screen flashes for 2 seconds to show the set temperature of 26 degrees two fans and two sets of PTC at the same time, Two motors are operating in second gear, Two sets of PTC open one gear power 1500W (MAX) / 1250W (PRO), Press the heating button again and the digital screen flashes for 2 seconds to show the set temperature of 27 degrees two fans and two groups of PTC open at the same time, Two motors are operating in second gear, Two sets of PTC open one gear power 1500W (MAX) / 1250W (PRO), Press the heating button again and the digital screen flashes for 2 seconds to show the set temperature of 28 degrees two fans and two groups of PTC open at the same time, Two motors are operating in second gear, Two sets of PTC open second gear power 3000W (MAX version) / 2500W (PRO version), Press the heating button again and the digital screen flashes for 2 seconds to show the set temperature of 29 degrees two fans and two groups of PTC open at the same time, Two motors are operating in second gear, Two sets of PTC open second gear power 3000W (MAX version)
/ 2500W (PRO version), then press the heating button digital screen flashing for 2 seconds to show the set temperature 30 degrees two fans and two sets of PTC are opened at the same time, two motors running in second gear, two groups of PTC open secondary power 3000W (MAX version) / 2500W (PRO version), press the heating button digital screen flashing for 2 seconds show 00 close the fan for 30 seconds. Press the primary heating button to flash the digital screen flashing for 2 seconds to display the set temperature 25 degrees two fans and two sets of PTC at the same time, two motors in the second gear, two groups of PTC on the first gear power 1500W (MAX version)
/ 1250W (PRO version).
Gear conversion key, continuous press is: low grade (25 degrees) low grade (26 degrees) low grade (27 degrees) high grade (28 degrees) high grade (29 degrees) high grade (30 degrees) 00 (off heating) low grade (25 degrees)..., cycle setting.
(If press the sleep button function switch to sleep mode heating indicator, temperature indicator, sleep indicator light, press a sleep button digital screen flashing 2 seconds display temperature 25 degrees sleep indicator light sleep mode two fan and two groups of PTC at the same time, two motors in a gear, two groups of PTC open power 1500W (MAX version) / 1250W (PRO version)
4. Sleep keys:
Press the sleep button to flash the digital screen for 2 seconds to show the temperature 25 degrees sleep indicator light on, heating indicator light, temperature indicator light on sleep mode two fans and two groups of PTC at the same time, two motors running in first gear, two groups of PTC open power 1500W (MAX version) / 1250W (PRO version). Again press the sleep button digital screen flashing 2 seconds heating off the digital screen display 00, again press the sleep button digital screen flashing 2 seconds display temperature 25 degrees sleep indicator light, heating indicator, temperature indicator light light sleep mode two fan and two groups of PTC at the same time, two motors in a gear, two groups of PTC open power 1500W (MAX version) / 1250W (PRO version).
5. Timing button:
Press the timing button timing indicator, time indicator light on, the first default number indicator (00) flashing, press a timing button for 1 hour timing, press a timing button for 2 hour timing....... Until the timing button is pressed for 12 hours, and when the timing button is 00, the timing indicator and time indicator are turned off. Press the timing button again for 1 hour timing.
